Description
The all-quartz flow-through cuvette is a high-precision cell for applications in spectroscopy. New technology enables the positioning of precise internal threads into the quartz glass. Tubes can now be connected very easily and securely directly to the cuvette.
The second path length is available by simply turning the cuvette through 90° – all tubes remain screwed in place. Time consuming changing of the cuvette is no longer necessary. Two different path lengths have a beneficial effect to the costs and the application. Furthermore, it is possible to measure the fluorescence with each optical path length – another benefit.
Fluorescence Sealable Cells 117.100F-QS
Specifications
Window Material: | Quartz glass high performance (QS) |
---|---|
Wavelength Range: | 200 – 2500 nm |
Width: | 12.5 mm |
Depth: | 12.5 mm |
Height: | 56 mm |
Light Path: | 10 mm |
Max Temperature: | Not Specified |
Fiber Optic Cable: | None |
Features
- No liquid leakage, monolithic quartz glass construction prevents this by design
- Suitable for high and low temperatures
- Fully autoclavable
- Secure tube connection is ensured due to the innovative quartz glass internal threads
Applications
- Spectroscopy
- Chemistry Labs
- Laser spectroscopy
Frequently Asked Questions
What is the Fluorescence Sealable Cells 117.100F-QS used for?
It is a high-precision cell used for applications in spectroscopy, chemistry labs, and laser spectroscopy.
What are the benefits of the two different path lengths?
The two different path lengths have a beneficial effect on the costs and the application. Furthermore, it is possible to measure the fluorescence with each optical path length.
Is the Fluorescence Sealable Cells 117.100F-QS leak-proof?
Yes, it is leak-proof due to its monolithic quartz glass construction.
Can the Fluorescence Sealable Cells 117.100F-QS be used in high and low temperatures?
Yes, it is suitable for high and low temperatures.
Is the Fluorescence Sealable Cells 117.100F-QS easy to connect to tubes?
Yes, it is easy to connect tubes to the cuvette due to the innovative quartz glass internal threads.
