Description

Acousto-optic tunable filters (AOTF) are used to rapidly and dynamically select a specific wavelength from a broadband or multi-line laser source. The device utilizes the acousto-optic principle in various anisotropic media. It control the wavelength of the transmitted light by controlling the RF signal acting on the AOTF transducer, and can also adjust the amplitude of the RF  signal to achieve the purpose of adjusting the intensity of the transmitted light.

Acousto-Optic Tunable Filter GA-AOTF-VIS-3-H1

Guangao Technology

Specifications

Wavelength Range: 400 – 650 nm
Number Of Wavelength Channels: 1
Max Diffraction Efficiency: 85 %
Polarization: Linear
Interaction Material: TeO2
Wavelength: 400-650 nm
Frequency: 75-140 MHz
Transmission: > 95 %
Active Aperture: 3 mm
Acoustic Mode: Shear wave
Input Optical Polarization: Linear, vertical to base
Output Optical Polarization: Linear, horizontal to base
Resolution: 2nm @ 525nm
VSWR: <3.0:1
Input Impedance: 50 Ω
RF Power: 2.0 W (Max.)
Diffraction Efficiency: >85%

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

The AOTF can filter both sound and light signals at the same and has a wide range of applications. It has good filtering effect and can achieve high-precision filtering. It has fast response speed and can achieve real-time filtering.

Applications

  • Confocal Microscopy
  • Laser Wavelength Turning
  • Fluorescence Imaging Technology
  • Spectroscopy
  • Imaging Spectroscopy

Frequently Asked Questions

What is the wavelength range for the Acousto-Optic Tunable Filter GA-AOM-VIS-3-H1?
The wavelength range for the GA-AOM-VIS-3-H1 is 400-650 nm.
What is the transmission efficiency of the GA-AOM-VIS-3-H1?
The transmission efficiency of the GA-AOM-VIS-3-H1 is greater than 95%.
What type of interaction material is used in the GA-AOM-VIS-3-H1?
The interaction material used in the GA-AOM-VIS-3-H1 is TeO2.
What is the maximum RF power for the GA-AOM-VIS-3-H1?
The maximum RF power for the GA-AOM-VIS-3-H1 is 2.0 W.
What is the diffraction efficiency of the GA-AOM-VIS-3-H1?
The diffraction efficiency of the GA-AOM-VIS-3-H1 is greater than 85%.
What is the active aperture size of the GA-AOM-VIS-3-H1?
The active aperture size of the GA-AOM-VIS-3-H1 is 3 mm.
What is the resolution of the GA-AOM-VIS-3-H1 at 525 nm?
The resolution of the GA-AOM-VIS-3-H1 at 525 nm is 2 nm.
