N 2/5 Piezo Multi Layer Ceramic Actuator Without Housing
piezosystem jena GmbH
PZT multilayer stack type actuators are made for industrial applications. They are specially shielded by a flexible insulation material which guarantees the highest possible dynamic performance under the toughest requirements. Based on their design, they are well suited for easy integration into specific customer systems. The ...
  • Motion Distance: 2 um
  • Resolution: 0.004 nm
Data Sheet
P 8/8 Stack Type Actuator Without Mechanical Preload
piezosystem jena GmbH
The series P of actuators are based on stack type actuators made by the multilayer technology. They come without a mechanical pre-load, but they still can withstand medium pressure forces. They should be used only in static applications. The piezo stack is encased in stainless steel housing with the top and bottom epoxide to ...
  • Motion Distance: 9 um
  • Resolution: 0.02 nm
Data Sheet
R 12/14 Ring Actuator
piezosystem jena GmbH
Piezoelectric ring actuators consist of a large number of contacted ceramic discs. Compared with the tube actuator, the ring actuator reaches a higher stiffness and the expansion is twice as high. The ring actuator is available with (series RA) and without (series R) housing. The actuator without housing is only connected at the ...
  • Motion Distance: 12 um
  • Resolution: 0.03 nm
Data Sheet
PICA Stack Piezo Actuator P-007.00
PI Ceramic GmbH
Operating voltage 0 to 1000 V. Long lifetime without derating. High specific displacement. High forces. Sub-nanometer resolution, µs response. Operating temperature range -20 to 85 °C.
  • Motion Distance: 5 um
  • Resolution: -- nm
Data Sheet
PICA Thru Ring Actuator P-010.00H
PI Ceramic GmbH
Operating voltage 0 to 1000 V. Long lifetime without derating. High specific displacement. A mechanical preload can be attached via inner holes.
  • Motion Distance: 5 um
  • Resolution: -- nm
Data Sheet
PICA Power Piezo Actuator P-010.00P
PI Ceramic GmbH
Operating voltage 0 to 1000 V. Long lifetime without derating. Large displacement, low electrical capacitance. Sub- nanometer resolution, µs response. Integrated temperature sensor to prevent damage from overheating. Extreme reliability: >109 cycles.
  • Motion Distance: 5 um
  • Resolution: -- nm
Data Sheet
Multi-Axes Mirror Positioning System PSH 1-4
Piezo Systems
The PSH 1 to PSH 4 series is based on piezo direct actuating systems. The systems are built like a tripod configuration. The PSH 1 through PSH 4 systems can be operated with the control of all three actuators simultaneously. A z-axis piston movement through a range of 33 µm can be achieved. Two different to plate sizes are available. ...
  • Motion Distance: 8 um
  • Resolution: 0.002 nm
Data Sheet
XYZ-Positioner microTRITOR
Piezo Systems
With the microTRITOR and miniTRITOR series, piezosystem jena offers 3D nanopositioning stages of the smallest size available. The dimensions of 15x15x15 mm3 and a motion range of 9 µm per axis make the microTRITOR the smallest 3D stage available on the market. The unique design of the flexure hinges allows for excellent ...
  • Motion Distance: 9 um
  • Resolution: 0.02 nm
Data Sheet
Z-Axis Piezo System PZ 10
Piezo Systems
The PZ 10 piezo electrical geared stage offers a vertical stroke of up to 10μm. As a result of the solid state phenomena the resolution is practically unlimited down to the sub-nm range. The FEA designed actuating system based on flexure hinges guarantees excellent guidance accuracy without parasitic motion. The durability of the ...
  • Motion Distance: 10 um
  • Resolution: 0.02 nm
Data Sheet
High Load Piezo Positioner nanoX 200
Piezo Systems
The one-axis linear positioning stages nanoX 200 are a development within the ultra-fast nanoX®-line. Due to FEA-optimization these stages achieve the highest dynamical performance and excellent guiding accuracy even under high loads. The positioning stages of the nanoX 200 series are temperature compensated – while ...
  • Motion Distance: 240 um
  • Resolution: 0.4 nm
Data Sheet
Piezo Positioner PXY 100
Piezo Systems
The systems of the series PXY 100 are ideally suited for nm-precise positioning of optic components such as mirrors and laser diodes, adjustment and mounting in semiconductor technologies and electronics, and applications in measurement technologies and quality assurance as well as microbiology. The series PXY 100 consist of piezo ...
  • Motion Distance: 100 um
  • Resolution: 0.2 nm
Data Sheet
Nanopositioning Element PU 100 SG
Piezo Systems
PU translators consist of a single metallic part which includes the flexure guiding system. This design means that PU translation stages show excellent mechanical stability and, because they are pre-loaded, can work dynamically. The FEA modeled flexures guarantee zero friction and high robustness. These actuators can support loads of ...
  • Motion Distance: 100 um
  • Resolution: 0.2 nm
Data Sheet
Nanopositioning Element PU 100
Piezo Systems
PU translators consist of a single metallic part which includes the flexure guiding system. This design means that PU translation stages show excellent mechanical stability and, because they are pre-loaded, can work dynamically. The FEA modeled flexures guarantee zero friction and high robustness. These actuators can support loads of ...
  • Motion Distance: 100 um
  • Resolution: 0.2 nm
Data Sheet
Ring Actuator R 12/14
Piezo Systems
Piezoelectric ring actuators consist of a large number of contacted ceramic rings. Based on their design they provide a 9 mm or 14 mm free aperture. Those make them especially suitable for integration into the laser beam line. Ring actuators are available with housing, series RA, and without housing, series R. The R series of ...
  • Motion Distance: 12 um
  • Resolution: 0.03 nm
Data Sheet
Stack Type Actuator Without Casing N 4/5
Piezo Systems
PZT multilayer stack type actuators are made for industrial applications. They are specially shielded by a flexible insulation material which guarantees the highest possible dynamic performance under the toughest requirements. Based on their design, they are well suited for easy integration into specific customer systems. The ...
  • Motion Distance: 4 um
  • Resolution: 0.008 nm
Data Sheet
Stack Type Actuator Without Casing N 2/5
Piezo Systems
PZT multilayer stack type actuators are made for industrial applications. They are specially shielded by a flexible insulation material which guarantees the highest possible dynamic performance under the toughest requirements. Based on their design, they are well suited for easy integration into specific customer systems. The ...
  • Motion Distance: 2 um
  • Resolution: 0.004 nm
Data Sheet
