Description
At Leoni Fiber Optics, we pride ourselves on offering an expansive portfolio of singlemode fibers, specifically designed to meet both current and future demands in various technological fields. Our Select-Cut-Off and polarization-maintaining singlemode fibers cover a broad wavelength range, extending from UV to IR. This makes them an ideal choice for applications in data transmission, optical communications, sensorics, and high-power laser transmission. These fibers are renowned for their superior geometrical specifications, high stability, and precise tolerances in fiber geometry, ensuring optimal performance and reliability.
Beyond our standard singlemode fibers, we provide a multitude of customization options to tailor the fiber design to specific customer applications. This includes adjusting the cut-off wavelengths from UV to IR and modifying mode field diameters to suit the desired operating wavelength. We accommodate customer-specific requirements for numerical aperture through the use of precise doping concentrations or specialized refractive index profiles. Furthermore, features such as reduced jacket geometry and adjusted dispersion are available to support the demanding applications of our clients.
Our singlemode fibers are coated with various materials such as acrylate, dual acrylate, high-temperature acrylate, or polyimide coatings. To ensure durability during operation across different temperature ranges or under chemical exposure, additional jacketing with Nylon or Tefzel buffer materials is available. All fibers can be customized and assembled to meet your specific application requirements, ensuring that you receive a product perfectly suited to your needs.
FiberTech Polarization-Maintaining Single Mode Fiber - 84820002F
Specifications |
|
|---|---|
| Mode Field Diameter: | 3.3 um |
| Wavelength Range: | 450 – 515 nm |
| Numerical Aperture: | 0.1 |
| Fiber Type: | Not Available |
Features
- Wide Wavelength Range: Our singlemode fibers support a broad spectrum from UV to IR, making them suitable for diverse applications.
- High Stability and Precision: These fibers offer excellent geometrical specifications with high stability and best tolerances in fiber geometry.
- Customizable Design: Tailor the fiber's design to meet specific application needs, including cut-off wavelengths, mode field diameters, and numerical apertures.
- Advanced Coating Options: Choose from acrylate, dual acrylate, high-temperature acrylate, or polyimide coatings for optimal performance under various conditions.
- Enhanced Protection: Additional jacketing with Nylon or Tefzel buffers ensures protection in different temperature ranges or against chemical influences.
- Customer-Specific Assemblies: Fibers can be assembled according to your specific application requirements for maximum efficiency.
- Bend-Insensitive and Polarization-Maintaining Options: Our FiberTech® singlemode special fibers include bend-insensitive and polarization-maintaining options for specialized needs.
- Optimized Transmission Properties: Our fibers provide excellent transmission properties with low attenuation across various wavelengths.
- Variety of Mode Field Diameters: Available mode field diameters range from 3.3 μm to 9.5 μm at different wavelengths, ensuring compatibility with your system.
- Multiple Jacket Diameters: Choose from a range of jacket diameters to suit your specific application needs.
- Additional Options: Further jacket diameters, cut-off wavelengths, coatings, and assemblies are available upon request.
Applications
- Data Transmission: Optimal for high-speed data transfer applications due to its excellent geometrical specifications and stability.
- Optical Communications: Ideal for use in optical communication systems, providing reliable and efficient signal transmission.
- Sensorics: Suitable for use in sensors that require precise and stable fiber optics.
- High-Power Laser Transmission: Capable of handling high-power laser applications with minimal loss and high stability.
- Customizable Design: Offers various options to adjust fiber design, including specific cut-off wavelengths, mode field diameters, and numerical apertures tailored to customer needs.
- Coating Options: Available with acrylate, dual acrylate, high-temperature acrylate, or polyimide coatings for protection in different environments.
- Additional Jacketing: Enhanced protection with Nylon or Tefzel buffer materials for operations in varied temperature ranges or under chemical exposure.
- Assembly Flexibility: Fibers can be assembled according to specific application fields, ensuring compatibility and performance.
- Bend-Insensitive Fibers: Designed to maintain performance even when bent, suitable for compact and flexible installations.
- Polarization-Maintaining Fibers: Ensures stable polarization, crucial for applications requiring precise light direction control.
Frequently Asked Questions
The transmission properties of Select-Cut-Off singlemode fibers include a wavelength range from 400–550 nm to 800–840 nm, cut-off wavelength ranging from 370 nm to 730 nm, attenuation ranging from 3.5 dB/km to 35 dB/km, and numerical aperture ranging from 0.10–0.14 to 0.14–0.18.
Yes, FiberTech Polariozation-Maintaining Single Mode Fiber can be customized according to specific cut-off wavelengths from UV to IR, mode field diameters at the desired operating wavelength, and customer-specific demands concerning the numerical aperture.
FiberTech Polariozation-Maintaining Single Mode Fiber is a type of singlemode special fiber that is ideal for data transmission, optical communications, sensorics, and high-power laser transmission.
FiberTech Polariozation-Maintaining Single Mode Fiber offers excellent geometrical specifications, high stability, and best tolerances in fiber geometry.
FiberTech Polariozation-Maintaining Single Mode Fiber can be coated with acrylate or dual acrylate, high-temperature acrylate, or polyimide coatings.
