Description
The base plate series is used to fix various mirror frames and rod frames. It is used as a base to facilitate connection with the workbench. It can also be used as a transition when various single adjustment frames are combined with multi-dimensional adjustment frames. The adjustment frame is connected and fixed to the optical platform. The base plate has various specifications and flexible selection. The hole spacing matches the company's products.
Base Plates Manual Stages
Specifications
| Mount Material: | Aluminum |
|---|---|
| Adjustments: | Tip and Tilt |
| Model: | LSGB1-4 |
| Installation Thickness: | 4mm |
| Installation Width: | 35-300mm |
| Net Weight: | 0.55kg |
| Model: | LSGB2-7 |
| Model: | LSGB2-16 |
| A: | 60 |
| A: | 90 |
| B: | 25 |
| B: | 26 |
| C: | 55 |
| C: | 65.5 |
| Installation Thickness Max: | 7 |
| Installation Thickness Max: | 16 |
| Net Weight: | 0.1kg |
| Net Weight: | 0.15kg |
| Model: | LSGB3-10 |
| Installation Thickness Range: | 0-10 |
| Installation Width: | 0-60 |
| Net Weight: | 0.25kg |
Download Data Sheet
Features
- Versatile Fixation: Used to secure various mirror and rod frames.
- Facilitates Connection: Acts as a base for easy attachment to workbenches.
- Transition Functionality: Enables combination of single and multi-dimensional adjustment frames.
- Secure Attachment: Ensures adjustment frames are firmly connected to the optical platform.
- Various Specifications: Offers multiple options for different needs.
- Flexible Selection: Provides a range of choices to match specific requirements.
- Compatible Hole Spacing: Designed to align with the company's product lineup.
Applications
- Optical Workbenches: Enhances stability and connectivity for optical components.
- Multi-Dimensional Adjustments: Allows seamless integration of various adjustment frames for complex setups.
- Precision Alignment: Ensures precise and stable alignment of optical elements in experimental setups.
- Laboratory Use: Ideal for use in research and development environments requiring versatile and reliable component fixation.
Frequently Asked Questions
What is the installation thickness for the LSGB1-4 model?
The installation thickness for the LSGB1-4 model is 4mm.
What are the dimensions for the LSGB2 series models?
The LSGB2-7 model has dimensions A=60, B=25, C=55, and a maximum installation thickness of 7mm. The LSGB2-16 model has dimensions A=90, B=26, C=65.5, and a maximum installation thickness of 16mm.
What is the net weight of the LSGB3-10 model?
The net weight of the LSGB3-10 model is 0.25kg.
What materials are used for the optical mounting bases?
The optical mounting bases are made of aluminum with a black anodized surface treatment.
What is the installation width range for the LSGB3-10 model?
The installation width range for the LSGB3-10 model is 0-60mm.
What is the purpose of the mounting bases?
The mounting bases are designed for mounting mirror mounts, optical posts/post holders, and mounting interfaces for optics and optical breadboards with standard mounting holes.
