Name: 6000W High Power Laser Welding Machine for Thick Metal
Brand: Jinan Acctek Machinery Co., Ltd.
Availability: InStock

Description

The 6000W High-Power Laser Welding Machine is an industrial-grade system designed for heavy-duty welding applications requiring high precision, deep penetration, and fast welding speeds. The high-power 6000W laser source provides the ability to weld metals such as stainless steel, carbon steel, and aluminum with greater depth and strength, ensuring clean and efficient welds even on thicker workpieces. This machine excels in applications requiring robust, high-performance welding, such as structural components, large-scale fabrication, and high-stress parts.

Equipped with advanced cooling systems, it operates reliably over extended periods, maintaining consistent welding quality. Additionally, the laser’s high precision reduces the heat-affected zone (HAZ), which minimizes distortion and material warping, making it ideal for precision parts and intricate joints. The 6000W High-Power Laser Welding Machine is also designed with user-friendly features, offering flexible control over welding parameters such as power, speed, and focus. This adaptability allows operators to optimize the process for various materials and applications. Whether for batch production or custom one-off projects, this machine provides the flexibility, power, and reliability needed for high-precision industrial welding tasks.

Specifications

Platform Type:	Portable
Materials:	Stainless Steel, Iron, Galvanized Steel, Aluminum, Brass, Copper
Welding Process:	Direct Laser Welding
Laser Type:	Fiber Laser
Laser Output Power:	6000 W
Laser Wavelength:	1064 nm
Laser Operation Mode:	Continuous Wave (CW)
Laser Cooling Mode:	Water-to-Water

Download Data Sheet

Features

High-Power Laser Source: The 6000W laser provides exceptional power for welding thick materials, offering deep penetration and strong weld seams. It is particularly effective on metals such as stainless steel, carbon steel, aluminum, and alloys, allowing for precise and robust welds even on thick sections.
High-Speed Welding: The powerful laser beam enables fast welding speeds, which significantly reduce production times and improve efficiency, especially in mass production or large-scale manufacturing environments.
Precision Control: Operators can easily adjust welding parameters like power, speed, focal length, and pulse frequency for precise control over the welding process. This flexibility is especially important for different material types, thicknesses, and joint configurations, allowing for customized weld quality.
Flexibility in Welding Thickness: This high-power system can handle a broad range of material thicknesses, from thin sheets to thick plates, making it suitable for both small and large-scale welding projects.
